Model 4055
Floor Waste Outlet, Fixed Toilet with Pivoting Oval Lavatory Cabinet
Cabinet consists of a stationary wall section and a hinged lavatory section which conceals the toilet. A latch is provided to lock the lavatory cabinet in the open or closed position. Cabinet frame requires floor and wall anchoring. The wall section has a front access panel and a removable top for easy installation and maintenance. This unit is configured with a floor waste connection.The wall section will increase with optional inclusion of Bedpan Washer and/or Dialysis Box Compartment.
Downloads
Resource Type | Title | Description | Answers | File Size | Action | |
|---|---|---|---|---|---|---|
 | | Fixed Toilet with Pivoting Oval Lavatory Cabinet [4050 | Wall Waste Outlet; 4055 | Floor Waste Outlet] also features instructions for Option -BW (Bedpan Washer); -DB (Dialysis Box Compartment) | 0 | 801 KB | ||
| | Fixed Toilet with Pivoting Oval Lavatory Cabinet [Standard Model 4050 (back waste), 4055 (floor waste) | 0 | 223 KB | ||
 | | 4050, 4055 Patient Care Unit with Fixed Toilet and Pivoting Oval Lavatory Cabinet | 0 | 181 KB | ||
| | 4050, 4055 Patient Care Unit with Fixed Toilet and Pivoting Oval Lavatory Cabinet | 0 | 950 KB | ||
 | | Whitehall Mfg - Healthcare water closets, Flushometer valves, Toilet seats, Patient care units, Healthcare showers, Healthcare shower valves, Healthcare bathing units, Bedpan washers | 0 | 320 KB | ||
| | Whitehall Mfg - Healthcare water closets, Flushometer valves, Toilet seats, Patient care units, Healthcare showers, Healthcare shower valves, Healthcare bathing units, Bedpan washers | 0 | 282 KB | ||
| | Who we are, Our History, Morris Group International Today | 0 | 7 MB | ||
| | MGI Brands Flyer (pdf) | 0 | 718 KB | ||
| | Polyethylene is available for Whitehall’s Patient Care Unit Care-Ware® products | 0 | 2 MB | ||
| | Cast Resin Colors for PCU Counter | 0 | 2 MB | ||
| | Whitehall Cleaning Guide for Stainless Steel, Enviro-Glaze Powder Coating, Corterra® Solid Surface, Plastic/Polyethylene, Resin & Laminate/Melamine Surfaces. | 0 | 928 KB | ||
 | | The Patient Care Unit is an innovative alternative to traditional restrooms in healthcare facilities. A PCU is a seamless single unit complete with a swing-out toilet, bed pan washer, antimicrobial custom resin countertop and sink. PCUs are ideal for all | 0 | 133 KB | ||
| | Plumbing Solutions for the Modern Healthcare Environment (video) | 0 | 131 KB |
Specifications
| PCU Toilet Type | Concealed by Pivoting Lavy Cabinet |
| Waste Location | Floor |
| Material | Stainless Steel Frame and Toilet, Various |
| Brand | Care-Ware®, Swingette® |
| CSI Divisions | Division 22 |
Options
Accessories
Miscellaneous
Image | Model | Description | Downloads | |
|---|---|---|---|---|
 | -SV | Option: Stainless Steel Valve(s) for Dialysis Box | ||
 | BL | Option: Bedpan Lugs | ||
 | BW | Bedpan Washer | ||
 | CCL | Option: Corterra® Solid Surface Countertop with Integral Lavy Bowl | ||
 | CCT | Option: Corterra® Solid Surface Countertop with Stainless Steel Drop-In Bowl | ||
 | CNCT | Corian Countertop with Stainless Steel Drop-In Bowl | ||
 | CNCTL | Corian Countertop with Integral Lavy Bowl | ||
 | CS | Stainless Steel Countertop with Integral Lavy Bowl | ||
 | DB1 | Dialysis Wall Box (Single Valve) | ||
 | DB2 | Dialysis Wall Box (Dual Valves) | ||
 | FCI | Option: Infectious Control Flush (for PCU) | ||
 | HET | High Efficiency Toilet (1.28 GPF) | ||
 | L | Left (Toilet Position) | ||
 | LCT | Less Countertop, Furnish with Lavy and Valve | ||
 | LCTL | Less Counter and Lavy, Furnish Valve | ||
 | LCTLV | Less Countertop, Lavy and Valve | ||
 | LLV | Less Lavy and Valve, Furnish Countertop | ||
 | LV | Less Valve, Furnish Countertop and Lavy | ||
 | MT (PCU) | Metal Template for PCU | ||
 | R | Right (Toilet Position) | ||
 | SO | Option: Sensor Operated Faucet with Gooseneck Spout | ||
 | SUG | Swing-Up Grab Bar | ||
 | ULF (Toilet) | Ultra Low Toilet Flush Valve (1.6 GPF) | ||
 | VF | Foot Operated Valve Control for Lavy | ||
 | WO3B | Option: 2-3/8 Inch P-Trap with 3 Inch Plain End Waste Outlet |
Models
Typical models are shown below features floor waste outlet
4055-L Lavy cabinet swings opens to the left 30" (762 mm) wide back back
4055-R-BW Lavy cabinet swings opens to the right Left extension of cabinet houses bedpan washer 38" (965 mm) wide back cabinet
4055-L-DB Lavy cabinet swings open to left Left extension of cabinet houses dialysis box 42" (1067 mm) wide back cabinet
4055-L-DB-BW Lavy cabinet swings open to left Left extension of cabinet houses dialysis box Right extension of cabinet houses bed pan washer 50" (1270 mm) wide back cabinet
Product Variations
Image | Model ID | Description |
|---|---|---|
 | 4050 | Back Waste Outlet, Fixed Toilet with Pivoting Oval Lavatory Cabinet |
