Name: BestCare® Ligature-Resistant Access Panel with Hydraulic Flush Valve
Brand: Whitehall Manufacturing
SKU: WH2898 Series

Model WH2898 Series

BestCare® Ligature-Resistant Access Panel with Hydraulic Flush Valve

**IMPORTANT: Refer to Whitehall Models WH2898-ADA-SL Series or WHD2898 Series for ADA in-wall Flush Valve applications incorporating Closure Plate Grab Bars.

Recommended for use with non-ADA Toilets and non-ADA and ADA Urinals with wall supply (concealed) flush valve connections where vandalism and ligature resistance is a concern.

The Hydraulic Flush Valve provided is a concealed type with a cast bronze body. The flush valve features quiet operation and includes a suicide-resistant pushbutton, union angle stop, and vacuum breaker.

The Flush Valve Access Panel is 16 gauge, type 304 stainless steel with all exposed surfaces powder-coated white. It is furnished with vandal-resistant screws.

CALIFORNIA WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov - Learn More about this warning

Downloads

Resource Type	Title	Description	File Size
Installation Instructions	Install Guide WH2898 Cover and Flush Valve (pdf)	BestCare® Ligature-Resistant Access Panel with Hydraulic Flush Valve	90 KB
Submittals	Submittal WH2898 Flush Valve with Cover (pdf)	BestCare® Ligature-Resistant Access Panel with Hydraulic Flush Valve For TOILET WH2898-1.28, WH2898-1.6, WH2898-3.5, WH2898-1.28-SS, WH2898-1.6-SS; For URINAL WH2898-0.5, WH2898-.125, WH2898-0.5-SS, WH2898-.125-SS LESS FLUSH VALVE AND PUNCH WH2898-BLANK	232 KB
Brochures/Flyers	MGI Corporate Brochure (pdf)	Who we are, Our History, Morris Group International Today	27 MB
Brochures/Flyers	MGI Brands Flyer (pdf)	MGI Brands Flyer (pdf)	718 KB
Brochures/Flyers	BestCare Solutions Flyer (pdf)	BestCare Solutions Flyer (pdf)	181 KB
Technical Data Sheets	Whitehall Cleaning and Care Guide (pdf)	Whitehall Cleaning Guide for Stainless Steel, Enviro-Glaze Powder Coating, Corterra® Solid Surface, Plastic/Polyethylene, Resin & Laminate/Melamine Surfaces.	928 KB
Brochures/Flyers	BestCare Ligature-Resistant Brochure (pdf)	BestCare Ligature-Resistant Brochure (pdf)	48 MB
Drawings	WH2898-ADA Flush Valve with Cover (rfa)	Ligature-Resistant Box with Hydraulic Flush Valve for Top Supply ADA Toilet	2 MB
Drawings	WH2898-ADA Flush Valve with Cover (dwg/zip)	Ligature Resistant Access Panel with Hydraulic Flush Valve	202 KB
Drawings	WH2898 Flush Valve Cover (rfa)	BestCare® Ligature-Resistant Access Panel with Hydraulic Flush Valve	492 KB
Drawings	WH2898 Flush Valve Cover (dwg/zip)	BestCare® Ligature-Resistant Access Panel with Hydraulic Flush Valve	226 KB
Videos	Behavioral Healthcare Webinar (video)	Vice President Kristin Kahle and National Sales Manager (Healthcare) Steve McIntosh discuss the importance of universal ligature resistant design within behavioral healthcare facilities.	134 KB

Can't find what you are looking for? Get in touch

Specifications

Shows specifications for standard configuration. Configuration options may change specifications.

Valve Type	Wall Supply - typically concealed in wall, Hydraulic pushbutton flush valve
CSI Divisions	Division 22
Material	Stainless Steel
Brand	BestCare®
Type of Mount	Valve in Recessed in Wall; Covered by Panel
Appropriate for	Ligature Resistant, Toilets

Models

Note: Formerly Cataloged as Model #WH2898-ADA

WH2898 Access Panel withFlush Valve used for WH2142-W Toilets ======================= 1.28 Gallons (4.85 Liters) per Flush White Powder Coat Finish WH2898-1.28[IN STOCK] ----------- All Stainless Steel WH2898-1.28-SS =============== 1.60 Gallons (6 Liters) per Flush White Powder Coat Finish WH2898-1.6[IN STOCK] ------------ All-Stainless Steel WH2898-1.6-SS =============== 3.5 Gallons (13.25 Liters per Flush White Powder Coat Finish WH2898-3.5

WH2898 Access Panel with Flush Valve used for WH2158W-SLPT-EB Urinal ====================== 0.125 Gallons (0.47 Liter) per Flush White Powder Coat Finish WH2898-.125 -------------- All-Stainless Steel WH2898-SS-.125-SS ============== 0.5 Gallons (1.89 Liter) per Flush White Powder Coat Finish WH2898-0.5 -------------- All-Stainless Steel WH2898-0.5-SS

WH2898-BLANK - Flush Valve Access Panel only, Blank, White Powder Coat Finish
